2.6 Gallon Dual-Power Foam Unit

#F100

Features

  • Dual operation with manual pump and connection for air supply for flexibility in applications
  • Connect to an air source to pressurize the unit, then disconnect and move the unit to the area to be cleaned
  • Produces thick, high quality foam
  • Lightweight, durable, and chemical-resistant discharge hose
  • Pressure regulator and pressure relief valve for safety
  • Viton seals for chemical compatibility
  • Natural color tank for easy visibility of product levels

Datasheet

2.6 Gallon Dual-Power Foam Unit

User Manual

2.6 Gallon Dual-Power Foam Unit

POWER TYPE

Compressed air or manual

CHEMICAL PICKUP TYPE

Draws from pre-mixed solution

NUMBER OF PRODUCTS UNIT CAN DRAW FROM

One product

CAPACITY

2.6 gallons (10 liters)

DISCHARGE LINE LENGTH/DIAMETER

6 ft. (1.8 m) hose, with 1/4 in. (6.4 mm) inside diameter

DISCHARGE WAND/TIP TYPE

Polypropylene trigger handle with 65˚ fan tip

OUTPUT DISTANCE

5-6 ft. (1.5-1.8 m)

OUTPUT VOLUME

3 gal/min (11.4 l/min)

FLOW RATE

0.5 gal/min (1.9 l/min)

PUMP SEALS

Viton

*Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings.

COMPRESSED AIR REQUIREMENTS

40 psi (3 bar) with 2-5 cfm (57-142 l/min)

LIQUID TEMPERATURE RANGE

40-100˚F (4.4-37˚C)

CHEMICAL COMPATIBILITY

Chemical products used with this equipment must be formulated for this type of application and compatible with unit materials and pump seals. For more information on chemical compatibility, consult the manufacturer or SDS for your product or contact our customer service department.

  • Complete unit
  • User manual
